MEMOLI ACH 65 CNC Hydraulic Press Brake
3-axis CNC tube bender for the linear bending of tubes up to 80 mm diameter.
The tube bending machines of the ACH series are fully automatic bending machines with CNC 3 axes: bending (Y axis), advancement (X axis) and rotation (Z axis).
This hybrid tube bender has been developed for the accurate bending of tubes and profiles. The main axes are electrically controlled, while the auxiliary axes are hydraulically controlled.
ACH Memoli
The extremely small bending head is made of steel with a chain-driven transmission to ensure more space in the sub-bending head; in this way, the machine can bend in a single cycle even tubes with the most complex geometries.
The setup times are extremely short and ensure great flexibility.
The ACH series of CNC mandrel tube bending machines is developed and produced entirely in Italy, in close collaboration with the main tube bending Companies.
General features
Carbon steel frame
Feasibility analysis thanks to the easy and intuitive 3D simulator
Primary axes handling with brushless CNC motors
Toggle lock closure
Programmable advance mandrel extraction
Bending with variable radius
Rear booster
Preparation for punching accessory – Up/Down mold opening
Compact and exposed bending head for maximum bending space
Separate control pulpit
Maximum capacity (mm)
| MATERIAL | ACH 65 |
|---|---|
| Max steel tube to bend with mandrel | 65 x 4 |
| Max steel tube to bend with interpolation | 60 x 3 |
| Max aluminium alloy tube to bend with mandrel | 80 x 3 |
| Max aluminium alloy tube to bend with interpolation | 65 x 3 |
